Rotel RB-1582 MKII Stero Power Amplifier

Rotel’s next largest stereo amplifier at 200 Watts per channel provides the massive current to drive the very largest Hi-Fi systems effortlessly. And like its smaller brother, the RB-1582 MkII has been designed to excel at resolving the subtle details in music as well as supplying the brawn required for extremely dynamic passages. It is able to achieve this difficult dual requirement because of the meticulous attention paid to circuit design and parts selection.

The RB-1582 MkII's high-end performance begins with an extremely large toroidal transformer combined with a total of 60,000µF storage capacity in special “slit foil” capacitors to provide completely stable power to the output stage. Slit foil capacitors have the ability to charge and discharge extremely quickly, thereby ensuring signal fidelity during orchestral crescendos or repetitive kick-drum impacts, for example. Both left and right channel construction are laid out in a mono block design (after the toroidal transformer) and all grounding is terminated in a star pattern on a copper grounding plate to ensure low signal to noise. The output stage is a discrete design that consists of 10 high current bipolar transistors per channel. Input options consist of both balanced XLR and unbalanced RCA connectors.

The RB-1582 MkII stereo power amplifier is yet another outstanding example of Rotel’s Balanced Design Concept and will form the heart of a very impressive stereo or home theatre system for years to come.

Features:

2 x 200 Watts of
robust power

Class AB amplifier
design

High-quality slit foil
capacitors made in
Britain

Balanced XLR inputs

12 volt trigger
Input

Specifications:
Dimensions

(W × H × D)
431 × 144 × 407mm
17" × 5.7" × 16"

Front Panel Height

3U / 132.6mm (5.25")

Power Requirements

230V, 50Hz

Power Consumption

550W

Standby Power Consumption

0.5W

Continuous Power Output

200W/Ch (All channels driven, 8Ω)

Net Weight

17.6kg (39lbs.)


*Product description, details and specification subject to change. Please check the manufacturer's website for the most recent information. Errors and omissions excepted.
