Dali Phantom S-180 In-Wall Speaker (Single)

5yr warranty
DUE SOON
More on the way - order now to avoid disappointment

Dali Phantom S-180 In-Wall Speaker (Single)

The slim DALI PHANTOM S-180 in-wall loudspeaker offers a full frequency response similar to that of a floorstanding loudspeaker, but without sacrificing valuable living room space. It delivers a no compromise in-wall audio performance with the use of proven speaker technologies. This includes our characteristic wood fibre cones, low-loss rubber surround, solid MDF front baffle, our signature hybrid tweeter module and our superior innovative magnet design including a SMC pole piece.

All models are built around a rotatable hybrid tweeter module making them easy to install for any audio use – be it stereo, centre channel or surround.

We have optimised the primary 8” wood fibre woofer for both bass and mid-range performance. To further enhance the bass performance, we have paired the primary woofer with a 10” passive carbon fibre radiator. This ensures that the PHANTOM S-180 really stands out from the crowd.

The ultra slim 103 mm cabinet design fits into almost any standard wall.

WIDE DISPERSION

All speakers by DALI are designed around the principle of wide dispersion. This entails an off-axis optimisation of the audio reproduction. The technology is perfect for use in install speakers, since they are always mounted flush against either a wall or ceiling.

SLIM CABINET

One of our goals for the PHANTOM S and M models was to create high-end in-wall speakers with a slim profile that allowed for maximum flexibility when installed. We achieved this by keeping the cabinet depths at only 100-103 mm, which fits into almost any standard wall.

SMC TECHNOLOGY

Advanced Soft Magnetic Compound (SMC), which eliminates variation of flux strength in the magnet gap. It reduces distortion to a minimum compared to conventional drivers.

10" PASSIVE RADIATOR

Featuring a 10" passive bass reflex woofer made of very well behaving carbon fibre - taken from our highend subwoofer 'DALI SUB P-10 DSS'

Specification
Product series PHANTOM
Frequency Range (+/-3 dB) [Hz] 49 - 25,000
Sensitivity (2,83 V/1 m) [dB] 89
Nominal Impedance [ohms] 6
Maximum SPL [dB] 109
Recommended Amplifier Power [W] 40 - 200
Crossover Frequency [Hz] 2,800 / 15,000
Hybrid tweeter module, Super high freq. driver, Diaphragm type
Hybrid tweeter module, High frequency driver, Quantity 1 x 17 x 45 mm
Hybrid tweeter module, High frequency driver Diaphragm type Ribbon
High frequency driver, Quantity 1 x 28 mm
High frequency driver, Diaphragm type Soft Textile Dome
Low frequency driver, Quantity 1 x 8"
Low frequency driver, Diaphragm type Wood Fibre Cone
Low frequency passive driver, Quantity 1 x 10"
Low frequency passive driver, Diaphragm type Carbon fibre cone
Enclosure type Closed Box With A Passive Radiator
Connection Input Single Wire
Recommended Placement In-Wall  / Centre / Soundbar
Dimensions (HxWxD) [mm] 898 x 453 x 110
Cut-Out Dimensions (HxWxD) [mm] 865 x 420 x 103
Weight [kg] 18.5
